Franklin Electric 4400 Tri-Seal 4-Inch Pumps

Franklin Electric 4400 Tri-Seal 4-Inch Pumps

Franklin Electric 4400 Tri-Seal 4-Inch Pumps

You'll find Franklin Electric 4400 Tri-Seal 4-Inch Submersible Pumps, controllers and accessories available at GG Pumps & Electrical.

Franklin Electric 4400 Tri-Seal 4" Submersible Pumps are available in two ranges:

• Standard Franklin FPS 4400 Tri-Seal 4" Submersible Pumps feature the new TRI-•SEAL floating stage system. This new stage system further improves efficiency and protects against wear when pumping abrasives like sand.

• High Capacity Franklin FPS 4400 Tri-Seal 4" Submersible Pumps are engineered for commercial, irrigation and residential use. Design advancements reduce efficiency losses caused by internal pump leakage and abrasives (sand).

Advice. Products. Solutions. Locally source and buy Franklin Electric FPS 4400 4" Tri-Seal Pumps from GG Pumps & Electrical your local Irrigear® Independent Experts — the leaders in pumping, irrigation, filtration, water and fluid management.

Franklin FPS 4400 Tri-Seal 4-Inch Pumps
Explore Franklin ElectricContact Us Today

Standard Franklin FPS 4400 Tri-Seal 4-Inch Pumps

Standard Franklin FPS 4400 Tri-Seal 4" Submersible Pumps feature the new TRI-SEAL floating stage system. This new stage system further improves efficiency and protects against wear when pumping abrasives like sand – therefore we will provide a 12 month guarantee on sandlocking! on top of the two-year warranty upon purchase. However, warranty will be further extended to three years for Pump and Motor acquisitions.

  • 1, 1.5, 2, 3, 3.5 and 4 m³/h flow ratings
  • 18, 25, 30, 45, 60 and 70 litres per min flow ratings
  • 300 series stainless steel hub floats with the impeller maintaining a positive seal
  • Phenolic washer provides high efficiency performance and abrasion resistance
  • Celcon®* impeller provides high efficiency performance and abrasion resistance
  • Noryl®** diffuser and disc - proven abrasion resistant material
  • Floating stage design allows impeller to float independently
  • Removable, spring-loaded check valve
  • Maximum water temperature: 120 °F/49 °C
  • Ceramic shaft sleeve and rubber discharge bearing protect shaft and eliminate sand wear
  • Powered by Franklin Electric corrosion-resistant 4" submersible motor
  • 12 Month Guarantee on Sand locking
  • Two-year warranty (Three-year warranty for Pump and Motor Purchases)

High capacity Franklin FPS 4400 Tri-Seal 4-Inch

High Capacity Franklin FPS 4400 Tri-Seal 4" Submersible Pumps are engineered for commercial, irrigation and residential use. Design advancements reduce efficiency losses caused by internal pump leakage and abrasives (sand). At Franklin we ensure such qualities through our 12 months guarantee against sandlocking and our two-year warranty on our pumps with an extra year added for pump and motor purchases.

  • 6, 9, 12 and 16 m³/h flow ratings
  • 100, 150, 200 and 270 litres per min flow ratings
  • Stainless Steel discharge head and motor bracket.
  • Guaranteed against sand locking in abrasive well conditions for one full year.
  • High flow impellers and stages are glass-filled Noryl™ for maximum efficiency.
  • Ceramic shaft sleeve and rubber discharge bearing eliminates sand wear.
  • Intermediate bearing for increased shaft stability.
  • Floating eye and hub seals improve performance and efficiency.
  • Stainless steel hex pump shaft, shell and shaft coupling.
  • High capacity upthrust assembly for protection during start-up and operation (9, 12 & 16 M³/H models).
  • Powered by Franklin Electric’s corrosion-resistant 4" submersible motor.
  • 2" BSPP discharge threads.
  • Supplied with external check valve.
  • 12 Month Guarantee on Sandlocking.
  • Two-year warranty (Three-year warranty for Pump and Motor Purchases)
Franklin Electric

Moving water is our business.

Franklin Electric is a global leader in the manufacture and distribution of pumps, motors, drives, controllers and world-leading solar pumping solutions for use in a wide variety of residential, commercial, agricultural, industrial and municipal applications.


Franklin Electric has over 75 years of experience providing Industry-leading technical service to the irrigation industry, providing support and advice even in the most rural areas. With a team of experts to ensure the highest quality of performance to keep you pumping now and into the future.


Franklin Electric – Leading the industry in service standards.




Talk to the team at GG Pumps & Electrical a member of Irrigear® Independent Experts to find out more about the range of Frankln Electric FPS TRI-SEAL 4" Submersible Pumps and other great Franklin Electric solutions!
